Hi-Fi full range speaker, 40WMAX, 20WRMS, 8Ω
HOBBY HiFi 03/2012
"Without a correction circuit, reaches its full potential ... an excellent 3" full range speaker available at an amazingly attractive price."
MONACOR product code: SPX-30M
TECHNICAL DATA:
Impedance (Z) | 8Ω |
Resonant frequency (fs) | 100Hz |
Max. frequency range | f3-20,000Hz |
Music power | 40WMAX |
Power rating (P) | 20WRMS |
SPL (1W/m) | 86dB |
Suspension compl. (Cms) | 1.23mm/N |
Moving mass (Mms) | 2.1g |
Mech. Q factor (Qms) | 3.453 |
Electr. Q factor (Qes) | 0.89 |
Total Q factor (Qts) | 0.71 |
Equivalent volume (Vas) | 1.78 l |
DC resistance (Re) | 6.4Ω |
Force factor (BxL) | 3.05Tm |
Voice coil induct. (Le) | 0.18mH |
Voice coil diameter | 20mm |
Voice coil former | Kapton |
Linear excursion (XMAX) | ±1.1mm |
Eff. cone area (Sd) | 32cm2 |
Magnet weight | 119g |
Weight | 0.5kg |
